FUEL INJECTOR CLEANING AND CALIBRATION
When performing the flow testing and calibration of your injectors, we cycle the injectors at:
FLOW RATE:
Static Flow
FLOW TEST PARAMETERS:
Static open position
REPRESENTATION:
Amount of fuel the pintle and orifice can physically flow. Diagnostic test - your motor does not perform at static flow.
RISKS IF OUT-OF-BALANCE:
Determine if the set of injectors are flowing sufficient fuel.
DESIRED % OF IMBALANCE:*
2% - 4%
* Optimax Fuel and Air injectors can have slightly higher percentage of imbalance.FLOW RATE:
5 MSEC @ 6,000 RPMs
FLOW TEST PARAMETERS:
Injectors are pulsed to simulate Wide Open Throttle (WOT)
REPRESENTATION:
Determine if injector and solenoid are operating correctly.
RISKS IF OUT-OF-BALANCE:
Extreme reduction in horsepower, loss of top speed RPM's, reduced fuel mileage, risk of damage.
DESIRED % OF IMBALANCE:*
2% - 4%
* Optimax Fuel and Air injectors can have slightly higher percentage of imbalance.FLOW RATE:
2 .5 MSEC @ 6,000 RPMs
FLOW TEST PARAMETERS:
Injectors are pulsed to simulate idle.
REPRESENTATION:
Determine if injector and solenoid are operating correctly.
RISKS IF OUT-OF-BALANCE:
Rough idle conditions, reduced fuel flow, reduced mileage.
DESIRED % OF IMBALANCE:*
2% - 4%
* Optimax Fuel and Air injectors can have slightly higher percentage of imbalance.SERVICES
Before Cleaning:
Each injector is numbered with etching underneath the connector - this numbering sequence will correspond to the Injector Calibration Report. If you are trying to diagnose an engine problem, you can number the injectors before sending to us and we will number and test the injectors based on your numbering.
• Inspect injectors for electrical resistance and shorting
• Remove injector screens and o-rings
• Individually flow test each injector at Static Flow, 5 MSEC, and 2.5 MSEC - recording results.
• Analyze spray pattern - noting irregularities.
• Bosch injectors are bead-blasted to remove old paint and corrosion.
Cleaning:
• Ultrasonically clean in heated bath solution while injectors are cycling
• Back-flush injector to remove contaminents
After Cleaning:
Individually flow test each injector at Static Flow, 5 MSEC, and 2.5 MSEC - until measurement stabilizes to 1/100 gram and continuously repeats. Rich or flooding injectors can be calibrated with customer approval. "See Mechanical Adjustment on the Service Request Form". Compute results of flow tests and generate a comprehensive injector calibration report. Bosch injectors are sealed with clear lacquer. Install new screens and o-rings. We will then contact customer (telephone and/or email) with results prior to returning shipment.
Turn-around Time:
Spring - 3-5 business days
Summer - 3-5 business days
Autumn - 2-3 business days
Winter - 2 business days
PRICING
| SERVICE | COST |
|---|---|
| Bosch / Keihin / Siemens | $25.00 per injector or $150.00 for a set of 6 |
| Removal/Reinstallation from crankcase injected fuel rail | $20.00 |
| Removal/Reinstallation from laser injection / fuel rail 2.5 and 3-Litre EFI | $25.00 |
| Optimax Sde-feed / Direct (Air) - Must be removed by the customer | $32.00 per injector or $192.00 for a set of 6 |
| HPDI - Must be removed by the customer | $25.00 per injector or $150.00 for a set of 6 |
| All other types of injectors (we do not service Evinrude E-Tec or diesel injectors) | $25.00 per injector or $150.00 for a set of 6 |
| Mechanical adjustment to top feed fuel injectors - over fueling / rich / flooding injectors only | $30.00 per injector |
| All O-rings and filter baskets to EFI motors | 25 cents each or $1.50 for a set of 6 |
| Optimax Air Injector seal kits / o-rings (as needed) | $4.00 each |
